Leupold RX-FullDraw 5 Rangefinder

by Leupold
Save 10% Save 10%
Original price $499.99
Original price $499.99 - Original price $499.99
Original price $499.99
Current price $449.99
$449.99 - $449.99
Current price $449.99

Built for the bowhunter and the competitive archer, the new RX-FullDraw® 5 is the most ballistically advanced archery rangefinder on the market. Using your bow’s velocity, peep height, your arrow weight, and the angles of your shots, it calculates laser-accurate ranges based on your specific gear.

Now, the RX-FullDraw 5 accepts an even broader range of velocity inputs, allowing you to input numbers as low as 170 feet per second. So, no matter what you shoot, this rangefinder has you covered. And with the updated flightpath technology, you can choose between two modes for viewing arrow obstructions out to a typical distance of 85 yards. It even has a setting for ranging in bad weather. When there’s moisture in the air, Last Target mode will punch through rain, fog, and snow to make sure you get an accurate reading.

Pair that with its six times magnification, bright red OLED display, and incredibly fast laser engine, and you’ll see why this rangefinder is guaranteed to give you the advantage that you’ve been looking for.

SPECIFICATIONS

Archery Angle Compensation TBR - Archery
Battery Type CR2
Magnification 6
Prism Lock No
Trophy Scale No
Tripod Compatible (1/4-20) No
True Ballistic Range - Wind (TBR-W) No
True Ballistic Range (TBR) No
Horizontal Distance (TRIG-H) Yes
Bow Mode No
True Golf Range (TGR) No
Length (in) 3.8
Width (in) 1.4
Height (in) 3
Weight (oz) 7.5
Objective Diameter (mm) 22
Linear FOV (ft@1000 yd) 315
Angular FOV (Degrees) 6
Eye Relief (mm) 17
Min Diopter (dpt) -3
Max Diopter (dpt) 3
Light Transmission (%) 85
Battery Life (Actuations) >3000
Accuracy to 125 (yd) .5
Accuracy to 1000 (yd) 2
Accuracy above 1000 (yd) % .5
Max Range - Deer (yd) 900
Max Range - Trees (yd) 1100
Max Range - Reflective (yd) 1200
Max Range - Golf Flag (yd) 0
Min Range (yd) 6
Laser Classification Class 1M
Pinhunter No
